Live Stream Manager

A professional Next.js web application for managing live streams and controlling multiple OBS Source Switchers with real-time WebSocket integration and modern glass morphism UI.

Features

• OBS Scene Control: Switch between OBS layouts (1-Screen, 2-Screen, 4-Screen) with dynamic button states
• Multi-Screen Source Control: Manage 7 different screen positions (large, left, right, and 4 corners)
• Real-time OBS Integration: WebSocket connection with live status monitoring
• Enhanced Stream Management: Create, edit, and delete streams with comprehensive OBS cleanup
• Team Organization: Organize streams by teams with full CRUD operations and scene synchronization
• Comprehensive Deletion: Remove streams/teams with complete OBS component cleanup (scenes, sources, text files)
• Audio Control: Browser sources created with muted audio and OBS control enabled
• Modern UI: Glass morphism design with responsive layout and accessibility features
• Professional Broadcasting: Audio routing, scene management, and live status indicators
• Dual Integration: WebSocket API + text file monitoring for maximum compatibility
• UUID-based Tracking: Robust OBS group synchronization with rename-safe tracking
• Enhanced Footer: Real-time team/stream counts and OBS connection status
• Optimized Performance: Reduced code duplication and standardized API responses

Quick Start

npm install
npm run dev

Open http://localhost:3000 to access the control interface.

Configuration

Environment Variables

Create .env.local in the project root:

# File storage directory (optional, defaults to ./files)
FILE_DIRECTORY=C:\\OBS\\source-switching

# OBS WebSocket settings (optional, these are defaults)
OBS_WEBSOCKET_HOST=127.0.0.1
OBS_WEBSOCKET_PORT=4455
OBS_WEBSOCKET_PASSWORD=your_password_here

# Security (IMPORTANT: Set in production)
API_KEY=your_secure_api_key_here

Security Setup

⚠️ IMPORTANT: Set API_KEY in production to protect your OBS setup from unauthorized access.

Generate a secure API key:

# Generate a random 32-character key
openssl rand -hex 32

Without an API key, anyone on your network can control your OBS streams.

OBS Source Switcher Setup

1. In OBS, configure Source Switcher properties
2. Enable "Current Source File" at the bottom
3. Point to one of the generated text files (e.g., large.txt, left.txt)
4. Set read interval to 1000ms
5. Sources will switch automatically when files change

Database Setup

The project includes an empty template database for easy setup:

# Option 1: Use template database directly (development)
# Database will be created in ./files/sources.db
npm run create-sat-summer-2025-tables

# Option 2: Set up custom database location (recommended)
# 1. Copy the template database
cp files/sources.template.db /path/to/your/database/sources.db

# 2. Set environment variable in .env.local
echo "FILE_DIRECTORY=/path/to/your/database" >> .env.local

# 3. Create tables in your custom database
npm run create-sat-summer-2025-tables

Template Database: The repository includes files/sources.template.db with the proper schema but no data. Your local development database (sources.db) is automatically ignored by git to prevent committing personal data.

Development Commands

npm run dev          # Start development server
npm run build        # Build for production
npm run start        # Start production server
npm run lint         # Run ESLint
npm run type-check   # TypeScript validation

Architecture

• Frontend: Next.js 15 with React 19 and TypeScript
• Backend: Next.js API routes with SQLite database
• OBS Integration: WebSocket connection + text file monitoring
• Styling: Custom CSS with glass morphism and Tailwind utilities
• CI/CD: Forgejo workflows with self-hosted runners

API Endpoints

Stream Management

• GET /api/streams - List all streams with team information
• GET /api/streams/[id] - Get individual stream details
• POST /api/addStream - Create new stream with browser source and team association
• PUT /api/streams/[id] - Update stream information
• DELETE /api/streams/[id] - Delete stream with comprehensive OBS cleanup:
  • Removes stream's nested scene
  • Deletes browser source
  • Removes from all source switchers
  • Clears text files referencing the stream

Source Control

• POST /api/setActive - Set active stream for screen position (writes team-prefixed name to text file)
• GET /api/getActive - Get currently active sources for all screen positions

Team Management

• GET /api/teams - Get all teams with group information and sync status
• POST /api/teams - Create new team with optional OBS scene creation
• PUT /api/teams/[teamId] - Update team name, group_name, or group_uuid
• DELETE /api/teams/[teamId] - Delete team with comprehensive OBS cleanup:
  • Deletes team scene/group
  • Removes team text source
  • Deletes all associated stream scenes
  • Removes all browser sources with team prefix
  • Clears all related text files
• GET /api/getTeamName - Get team name by ID

OBS Group/Scene Management

• POST /api/createGroup - Create OBS scene from team and store UUID
• POST /api/syncGroups - Synchronize all teams with OBS groups
• GET /api/verifyGroups - Verify database groups exist in OBS with UUID tracking
  • Detects orphaned groups (excludes system scenes)
  • Identifies name mismatches
  • Shows sync status for all teams

OBS Scene Control

• POST /api/setScene - Switch OBS to specified scene (1-Screen, 2-Screen, 4-Screen)
• GET /api/getCurrentScene - Get currently active OBS scene

System Status

• GET /api/obsStatus - Real-time OBS connection, streaming, and recording status

Authentication

All endpoints require API key authentication when API_KEY environment variable is set.

See CLAUDE.md for detailed architecture documentation and implementation details.

Known Issues

Text Centering

• Issue: Team name text overlays position left edge at center instead of centering the text itself
• Workaround: Manually change "Positional Alignment" to "Center" in OBS UI
• Status: Under investigation - requires further research into OBS API behavior

System Scene Exclusion

Infrastructure scenes containing source switchers are excluded from orphaned group detection:

• 1-Screen, 2-Screen, 4-Screen, Starting, Ending, Audio, Movies
• Additional scenes can be added to the SYSTEM_SCENES array in /app/api/verifyGroups/route.ts
